Building a Tic-Tac-Toe CLI Game: Representing the Board and Detecting Winners
I recently coded up a quick’n dirty command line tic-tac-toe game as part of a coding exercise.
It seems like a simple task but actually involved some compelling challenges, in particular conceiving of how to represent the board so that its current state could be displayed on the command line and, more importantly, evaluated after each turn for a winning scenario (or stalemate, as the case may be). It was rewarding enough of a puzzle that I wanted to share some of my thinking, go through the various options I explored, and discuss why I ended up making the decision that I did.
Solution 1: 3 x 3 Matrix with Bitwise Operations to Detect Winners
My first thought was to represent the board with a 3 x 3 matrix of characters: ‘X’ and ‘O’ for player tokens and a blank ‘ ‘ for an unoccupied square. The initialization would look like this:
board = [[' ', ' ', ' '],
[' ', ' ', ' '],
[' ', ' ', ' ']]
What was appealing about this solution was that it made setting and getting super intuitive. If player1 makes their first move in the top right corner (i.e., row 0 and column 2), updating the board would be as simple as:
row = 0
col = 2
board[row][col] = 'X' # -> [[' ', ' ', 'X'],[' ', ' ', ' '],[' ', ' ', ' ']]
This solution also had the advantage of lending itself to straightforward display, since printing the current board state would be a matter of looping through the outer array for each row.
In it’s simplest form:
# Super simply display function
def display_matrix_simple(board):
for row in board:
print(''.join(row))
# Get a few more moves in there
board[2][0] = 'O'
board[2][1] = 'X'
board[1][2] = 'O'
display_matrix_simple(board)
X
O
OX
A prettier printing function could look like this:
def display_matrix(board):
out = ' | | \n '
out += '\n___|___|___\n | | \n '.join([' | '.join(row) for row in board])
out += '\n | | '
return out
print(display_matrix(board))
| |
| | X
___|___|___
| |
| | O
___|___|___
| |
O | X |
| |
That’s all well and good, but how to evaluate a winning position?
This is where bitwise operations come in. There are 8 winning combinations in tic-tac-toe: the three rows, the three columns, and the two diagonals. My thought was that each of these could be represented by a binary value. For instance, a diagonal winner would look like this:
[[1, 0, 0],
[0, 1, 0],
[0, 0, 1]]
Or, in a flattened form: [1, 0, 0, 0, 1, 0, 0, 0, 1]
Or, as a binary string: 0b100010001
Or, as an integer: 273
Encoding all 8 winning positions would look like this:
winners = [
0b111000000,
0b000111000,
0b000000111,
0b100100100,
0b010010010,
0b001001001,
0b100010001,
0b001010100
]
That means if we encode a given player’s positions such that 1 represents a position occupied by that player and a 0 a position occupied by the other player or unoccupied, we can use bitwise & for each of the 8 combinations to evaluate whether the result is indeed a winner.
This means a few additional steps:
- flattening our 3x3 array into a single list of length 9
- encoding this as a binary string for a given player token
- returning the integer value of that binary string
Here are some helper functions we’ll need:
def flatten(board):
return [item for row in board for item in row]
def flat_to_binary(flat_board, playerchar):
binseq = '0b'
for char in flat_board:
if char == playerchar:
binseq += '1'
else:
binseq += '0'
return binseq
def binary_to_int(encoded):
return int(encoded, 2)
Now let’s see them in action:
board = [['X', 'O', ' '],
['X', ' ', 'O'],
['O', 'X', 'X']]
print("Pretty display of board:")
print(display_matrix(board))
print()
print("Flattened board: {}"
.format(flatten(board)))
print()
print("Binary encoding of board for token 'X': {}"
.format(flat_to_binary(flatten(board), 'X')))
print()
print("Integer equivalent of binary encoding of board for token 'X': {}"
.format(binary_to_int(flat_to_binary(flatten(board), 'X'))))
Pretty display of board:
| |
X | O |
___|___|___
| |
X | | O
___|___|___
| |
O | X | X
| |
Flattened board: ['X', 'O', ' ', 'X', ' ', 'O', 'O', 'X', 'X']
Binary encoding of board for token 'X': 0b100100011
Integer equivalent of binary encoding of board for token 'X': 291
Now all we have to do is loop through the 8 winning board combinations and see if our encoded board & the current winner == the current winner. If so, we’ve got a winner!
In practice:
def is_winner(encoded):
for winner in winners:
if winner & encoded == winner:
return True
return False
board = [['X', 'O', ' '],
['X', ' ', 'X'],
['X', 'O', 'O']] # -> To be encoded as '100101100' for 'X'
print(display_matrix(board))
print("Winner for 'O'? {}"
.format(is_winner(binary_to_int(flat_to_binary(flatten(board), 'O')))))
print("Winner for 'X'? {}"
.format(is_winner(binary_to_int(flat_to_binary(flatten(board), 'X')))))
| |
X | O |
___|___|___
| |
X | | X
___|___|___
| |
X | O | O
| |
Winner for 'O'? False
Winner for 'X'? True
There are definitely some extra steps involved here: every time we want to evaluate the current board state for a winner, we would have to flatten it, encode it to binary and then as an integer for the current player, and then compare the encoded board state to each of the 8 winning combination boards. But the flip side is that we get a 3x3 board representation that is intuitive and easy to set/get.
Incidentally, the same procedure would be used to compute a stalemate, except for a stalemate we’d want to know whether each player’s position plus all the unoccupied squares contains a given winner. If not, then that’s a stalemate, baby!
Solution 2: Same as Above, but 1x9 List Instead of 3x3 Matrix
What appealed to me about the above solution was it’s intuitiveness: Representing a 3x3 tic-tac-toe game as a 3x3 matrix makes sense. But under the hood we’re constantly having to flatten that matrix in order to do anything with it.
As such, another option is to simply represent the board and its current state as a list to begin with, thus obviating the need for flattening. On the flipside, this means an extra step when setting/getting board positions, since we’d need to convert row/column input to a list index, but this is easily solved with a function like this:
def get_index(row, col):
return row * 3 + col
row, col = 1, 2
print("Row {} and column {} -> index {}".format(row, col, get_index(row, col)))
row, col = 2, 0
print("Row {} and column {} -> index {}".format(row, col, get_index(row, col)))
row, col = 0, 1
print("Row {} and column {} -> index {}".format(row, col, get_index(row, col)))
Row 1 and column 2 -> index 5
Row 2 and column 0 -> index 6
Row 0 and column 1 -> index 1
An update function could thus look like this:
def update_board(row, col, player_token):
board[get_index(row, col)] = player_token
And a slightly more complicated display function would look like this:
def display_flat(board):
out = ' | | \n'
row_start = 0 # Pointer to keep track of where each row starts
rows = []
# Separate `board` list into three rows
while row_start < len(board):
rows.append(' ' + ' | '.join(board[row_start:row_start + 3]) + ' \n')
row_start += 3
# Join rows
out += '___|___|___\n | | \n'.join(rows)
out += ' | | \n'
return out
Now we can do all of the above, but without the need for a flatten() function or method.
board = ['X', 'O', ' ', 'X', ' ', 'X', 'X', 'O', 'O']
print("Board:")
print(board)
print()
print("Pretty display of board:")
print(display_flat(board))
print()
print("Binary encoding of board for token 'X': {}"
.format(flat_to_binary(board, 'X')))
print("Integer equivalent of binary encoding of board for token 'X': {}"
.format(binary_to_int(flat_to_binary(board, 'X'))))
print("Winner for 'X'? {}"
.format(is_winner(binary_to_int(flat_to_binary(board, 'X')))))
print()
print("Binary encoding of board for token 'O': {}"
.format(flat_to_binary(board, 'O')))
print("Integer equivalent of binary encoding of board for token 'O': {}"
.format(binary_to_int(flat_to_binary(board, 'O'))))
print("Winner for 'O'? {}"
.format(is_winner(binary_to_int(flat_to_binary(board, 'O')))))
Board:
['X', 'O', ' ', 'X', ' ', 'X', 'X', 'O', 'O']
Pretty display of board:
| |
X | O |
___|___|___
| |
X | | X
___|___|___
| |
X | O | O
| |
Binary encoding of board for token 'X': 0b100101100
Integer equivalent of binary encoding of board for token 'X': 300
Winner for 'X'? True
Binary encoding of board for token 'O': 0b010000011
Integer equivalent of binary encoding of board for token 'O': 131
Winner for 'O'? False
This solution seems a little more complicated, but I gravitate to it since it represents the board in the format that the board is operated on, rather than in a human-friendly format that then needs to be converted to a flattened version to be operated on.
Spoiler alert: this is the solution I picked!
Solution 3: 3x3 Integer Matrix and Matrix Operations to Detect Winners
My first two solutions both used bitwise operations to detect winners. This third solution is different since it uses matrix operations to fulfill this function: If 1 represents a position held by player 1, -1 a position held by player 2, and 0 an unoccupied position, then if the sum of any row, column, or diagonal at any point is 3, then player 1 has won. Likewise, if at any point a row, column, or diagonal sums to -3, player 2 has won.
The advantage here is a more intuitive way of detecting winners than hard-coding binary encodings of winning boards.
The disadvantage is that we have to constantly translate the computer-friendly board consisting of 1s, -1s, and 0s (which is simple to perform some matrix operations on) to a human-friendly board consisting of X’s and Os.
board = [[ 1, -1, 0],
[ 0, 0, 1],
[-1, -1, 1]]
def convert(board):
char_matrix = []
for row in board:
new_row = []
for val in row:
match val:
case 1:
new_row.append('X')
case -1:
new_row.append('O')
case _:
new_row.append(' ')
char_matrix.append(new_row)
return char_matrix
print("Board:")
for row in board:
print(row)
print()
print("Converted to human readable:")
print(display_matrix(convert(board)))
Board:
[1, -1, 0]
[0, 0, 1]
[-1, -1, 1]
Converted to human readable:
| |
X | O |
___|___|___
| |
| | X
___|___|___
| |
O | O | X
| |
To detect a winner, we need to be able to sum the rows, columns, and diagonals.
Summing the rows is easy:
def is_winning_combo(combo_sum):
if combo_sum == 3:
return "Winner for player 1"
elif combo_sum == -3:
return "Winner for player 2"
else:
return "No winner"
def sumrows(board):
rowresults = []
for row in board:
result = 0
for col in row:
result += col
rowresults.append(result)
return rowresults
rowsums = sumrows(board)
print("Board:")
print(display_matrix(convert(board)))
print()
for i, rowsum in enumerate(rowsums):
print("Sum of row {}: {} --> {}".format(i, rowsum, is_winning_combo(rowsum)))
Board:
| |
X | O |
___|___|___
| |
| | X
___|___|___
| |
O | O | X
| |
Sum of row 0: 0 --> No winner
Sum of row 1: 1 --> No winner
Sum of row 2: -1 --> No winner
Summing the main diagonal is also easy, since we’re looking only at positions where row == col:
def sumdiag(board):
n = len(board)
result = 0
for i in range(n):
result += board[i][i]
return result
diagsum = sumdiag(board)
print("Board:")
print(display_matrix(convert(board)))
print()
print('Sum of main diagonal: {} --> {}'.format(diagsum, is_winning_combo(diagsum)))
Board:
| |
X | O |
___|___|___
| |
| | X
___|___|___
| |
O | O | X
| |
Sum of main diagonal: 2 --> No winner
Summing the columns and anti-diagonal, though, are a a little more annoying.
My solution is to rotate the matrix 90 degrees, and then we can sum the rows as above to compute the column sums and sum the main diagonal, also as above, to compute the anti-diagonal sum.
To rototate the board 90 degrees clockwise requires a few intermediary steps:
- Transpose the mirrored board (i.e., mirror the board over the main diagonal)
- Mirror the transposed board from left to right (i.e., reverse each row in the board variable)
The result of these two steps is a rotated matrix.
def reverse_row(row):
newrow = []
i = len(row) - 1
while i >= 0:
newrow.append(row[i])
i -= 1
return newrow
def mirror(board):
newboard = []
for row in board:
newboard.append(reverse_row(row))
return newboard
def transpose(board):
newboard = [['','',''],['','',''],['','','']]
for row in range(len(board)):
for col in range(len(board[row])):
newboard[row][col] = board[col][row]
return newboard
def rotate90(board):
return mirror(transpose(board))
print("Original Board:")
print(display_matrix(convert(board)))
print()
print("Mirrored Board:")
print(display_matrix(convert(mirror(board))))
print()
print("Transposed Board:")
print(display_matrix(convert(transpose(board))))
print()
print("90-Deg Rotated (i.e., Mirrored and Transposed) Board:")
print(display_matrix(convert(rotate90(board))))
print()
Original Board:
| |
X | O |
___|___|___
| |
| | X
___|___|___
| |
O | O | X
| |
Mirrored Board:
| |
| O | X
___|___|___
| |
X | |
___|___|___
| |
X | O | O
| |
Transposed Board:
| |
X | | O
___|___|___
| |
O | | O
___|___|___
| |
| X | X
| |
90-Deg Rotated (i.e., Mirrored and Transposed) Board:
| |
O | | X
___|___|___
| |
O | | O
___|___|___
| |
X | X |
| |
Now that we have a rotated board, we can simply sum the rows and the main diagonal as before:
print("Original Board:")
print(display_matrix(convert(board)))
print()
# Rotate board
rotated = rotate90(board)
# Compute columns sums (i.e., rows of rotated board)
rowsums = sumrows(rotated)
for i, rowsum in enumerate(rowsums):
print("Sum of col {}: {} --> {}".format(i, rowsum, is_winning_combo(rowsum)))
# Compute anti-diagonal sum (i.e., main diagonal of rotated board)
diagsum = sumdiag(rotated)
print('Sum of anti-diagonal: {} --> {}'.format(diagsum, is_winning_combo(diagsum)))
Original Board:
| |
X | O |
___|___|___
| |
| | X
___|___|___
| |
O | O | X
| |
Sum of col 0: 0 --> No winner
Sum of col 1: -2 --> No winner
Sum of col 2: 2 --> No winner
Sum of anti-diagonal: -1 --> No winner
This solution definitely involves a little extra work when it comes to computing winners, but it has the effect of being generalizable to an NxN tic-tac-toe game, whereas the bitwise solutions above require solutions that are hard-coded in. This solution is also more computationally intensive since we have to constantly be transforming the board in order to calculate the various row and column sums.
Solution 4: 3x3 Integer Matrix, but with NumPy
Above I had to code several functions to transform the board and sum the rows, columns, and diagonals. But we can also just leverage NumPy to accomplish the same thing:
import numpy as np
board = np.array([[1, -1, 0], [0, 1, 1], [-1, -1, 1]])
print(display_matrix(convert(board)))
| |
X | O |
___|___|___
| |
| X | X
___|___|___
| |
O | O | X
| |
board
array([[ 1, -1, 0],
[ 0, 1, 1],
[-1, -1, 1]])
x = board.sum(axis=1)
for i, rowsum in enumerate(x):
print("Sum of row {}: {} --> {}".format(i, rowsum, is_winning_combo(rowsum)))
Sum of row 0: 0 --> No winner
Sum of row 1: 2 --> No winner
Sum of row 2: -1 --> No winner
print(display_matrix(convert(board)))
print()
# Sum rows
rowsums = board.sum(axis=1)
for i, rowsum in enumerate(rowsums):
print("Sum of row {}: {} --> {}".format(i, rowsum, is_winning_combo(rowsum)))
# Sum cols
colssums = board.sum(axis=0)
for i, colssum in enumerate(colssums):
print("Sum of col {}: {} --> {}".format(i, colssum, is_winning_combo(colssum)))
# Sum main diagonal
diagsum = board.diagonal().sum()
print("Main dagonal sum: {} --> {}".format(diagsum, is_winning_combo(diagsum)))
# Sum anti-diagonal
antidiagsum = np.fliplr(board).diagonal().sum()
print("Anti-dagonal sum: {} --> {}".format(antidiagsum, is_winning_combo(antidiagsum)))
| |
X | O |
___|___|___
| |
| X | X
___|___|___
| |
O | O | X
| |
Sum of row 0: 0 --> No winner
Sum of row 1: 2 --> No winner
Sum of row 2: -1 --> No winner
Sum of col 0: 0 --> No winner
Sum of col 1: -1 --> No winner
Sum of col 2: 2 --> No winner
Main dagonal sum: 3 --> Winner for player 1
Anti-dagonal sum: 0 --> No winner
Conclusions
Of these solutions, I opted to go with solution 2:
- Use a flat list to represent the board.
- Detecting winners by encoding flat list to binary and comparing with known solutions
Disadvantages:
- 8 winning positions are hard-coded (although this could easily be automated to accommodate an NxN size board)
- Setting/getting involve an extra step in order to convert from row/column accessors to a single index accessor
- Non-intuitive representation of board
Advantages:
- Computationally simple winner detection
- Human-friendly board consisting of player token characters rather than integers
- Can accommodate games consisting of K players
